Specification |
|
Eyepiece |
Wide field WF10X(field number:¦µ22mm) |
|
Centering telescope |
|
Infinity and long working distance plan achromatic objective |
Objective |
PLL 10X0.25 Work distance：4.3 mm£¬Cover glass thickness：1.2mm. |
|
PLL 20X0.40 Work distance：8.0 mm£¬Cover glass thickness：1.2mm. |
|
PLL 40X0.60 Work distance：3.5 mm£¬Cover glass thickness:1.2mm. |
|
Phase Contrast Objective |
PLL 10X0.25 PHP2 Work distance：4.3 mm£¬Cover glass thickness：1.2mm. |
|
Eyepiece tube |
Inclination angle is 45˚ and interpupillary distance is 53~75mm. |
|
Focus system |
Coaxial coarse/fine focus, with tension adjustable and up stop minimum division of fine focusing is 2μm. |
|
Nosepiece |
Quintuple nosepiece |
|
Stage |
Fixed stage overall size is 227mmX208mm |
|
Glass rotundity stage overall size is Ф118mm |
|
Mechanical moving device, moving range is 77mm (longitudinal)X114mm (transverse) |
|
Culture dish holder 1 |
Inside locating slot size: 86mm (W)X129.5mm (L), optional with a circular culture dish Ф87.5mm |
|
Culture dish holder 2 |
Inside locating slot size: 34mm (W)X77.5mm (L), optional with a circular culture dish Ф68.5mm |
|
Culture dish holder 3 |
Inside locating slot size:：57mm (W)X82mm (L) |
|
Condenser system |
Long working distance condenser, working distance: 55mm, and with turnplate phase contrast unit |
|
Illumination system |
6V30W halogen, brightness enable control |
|
Filter |
Frosted glass and blue , green filter |
